OBDStar DC706

OBDStar DC706 can flash the memory of control units. Its advantage is universal support for most commonly used units via OBD and Bench methods.

Functions

• R/W EEPROM/DFlash/PFlash/Map, ECU reset (Virgin), mileage calibration, IMMO PIN code reading, ECU recovery
• Supports more than 1770 ECM types (some functions require optional P003 adapter)
• Supports more than 340 TCM types
• Support for more than 160 types of body control modules/other ECUs (Airbag, BCM, BSI, CEM, DDM/PDM, DIM, EPS, Keyless (RFHUB/RFHM), KVM, RFA, SAM...)
• Support for mileage calibration for VW DQXXX (TCM)
• Support for cloning Delphi MT05, MT05.2, MT05.3 motorcycle ECUs
• Support for cloning BRP ME17.8.5 motorcycle ECUs (optional P003 adapter required)
• Support for cloning Piaggio series engine control units (e.g., MIU G4 (M4G1))
• Support for smart search by brand, model, part number, ECU manufacturer, MCU type
• Support for automatic identification
• Extensive database with auxiliary files.
• All via OBD or Bench mode.

Supported units

Supported ECUs

Acdelco, Alps, ATE, Autoliv, Bosch, Continental, Delphi, Denso, Denso dece1c, Efi, Getrag, GM, Jc, Kefico, Lear, Magneti Marelli, Marelli, Siemens, Simtec, Temic, Valeo, Visteon, Yazaki, ZF

Supported passenger cars

Aston Martin, BMW, Faw, FCA (Alfa Romeo, Chrysler, Dodge, Fiat...), Ford/Lincoln, GM/Opel, Hyundai/Kia, Land Rover/Jaguar, Luxgen, Maserati, Mazda, Mitsubishi, Nissan, Opel, PSA, Smart, Subaru, Suzuki, Volvo, VW/Audi/Seat/Skoda, ...

Supported motorcycles

Aprilia, BRP, CFmoto, Derbi, Gilera, Guzzi, Italjet, Peugeot, Piaggio, Qjbenelli, Vespa

Updates

With your purchase, you will receive free updates for 1 year. After the free updates expire, further updates are not mandatory. New updates can be purchased at a discounted price after the existing ones expire. Updates can also be purchased later after skipping a certain period, but the price may be higher.

Why choose OBDSTAR DC706?

• Easy flashing of a wide range of units
• Affordable solution

Hardware Specifications

• Operating System: Android 5.1.1
• Processor: Quad-core processor
• Memory - Storage: 16 GB
• Display: 7" touchscreen with a resolution of 1024 x 600 pixels
• Operating temperature: -20 - 55 °C
• Storage temperature: -20 - 70 °C
• Operating humidity: 5 - 95% (non-condensing)
• Battery capacity: 3700 mAh

Optional accessories (not included, can be purchased separately)

• TCU Kit with adapters for connecting automatic transmission units
• P003 kit for Bosch ME17XX, MED17XX, EDC17XX and Continental PCR2.1 control units (VW, Škoda, Audi, Seat, Bentley, Peugeot, Citroën/DS, Lamborghini, Porsche, Mahindra).
• P003+ kit compatible with P003 to support the following models that require a higher clock signal frequency during the decryption process: ME9.0, MED9.1, MED9.6.1, ME9.6.1, MED9.5.10, EDC16C39, EDC16CP35, EDC16C8.
• MP001 kit compatible with P003+. Simos 18 requires more than what P003+ offers – its special startup mode needs more I/O ports than P003+ has (which only has 4 I/O ports and therefore does not support it). MP001 has 12 I/O ports and meets all ECM control unit requirements.

Package Content

• OBDSTAR DC706 Full Kit
• OBD-II cable
• P004 adapter
• Multifunctional cable for flashing ECUs
• Cable with jumpers
• 3-in-1 cable with jumpers
• Charger
• User manual
